Aiuto....ricreare nand retail da falcon rgh2 per passaggio r-jtag

**coffettierik** · 05-09-14

Salve a tutto il forum .... sto cercando aiuto per quanto riguarda il riportare una falcon da rgh2 a retail ....
ho provato a seguire il tutorial , ho estratto i file dal freeboot , sostituito il file smc.bin ma la console non parte .....
ho provato tutte le dashborad dalla 14717 alla 16537 che è quella attuale in rgh2 ma nulla da fare , non so più come fare....
cè qualcuno che può darmi una mano o un consiglio???? grazie in anticipo

**thunderbirddd** · 05-09-14

Secondo me fai prima a reperire una donor e metterci la tua key

**coffettierik** · 05-09-14

ciao, ma seguendo la guida non dicono di procurarsi una donor.... lo si può fare tranquillamente da quella attuale in freeboot

**zeruel85** · 05-09-14

Posta una schermata di xell intanto. Con i fuseset ovviamente.

Inviato dal mio GT-I8150 utilizzando Tapatalk

**coffettierik** · 05-09-14

Purtroppo ho già smontato tto ...comunque i fuseset aveva 4 f....
se vuoi ti posto i dati che mi rilascia j-runner della relativa nand freeboot

**zeruel85** · 06-09-14

Serve la tabella completa. Dire che un fuseset aveva 4 effe non significa nulla.

Inviato dal mio GT-I8150 utilizzando Tapatalk

**coffettierik** · 06-09-14

ciao....ho rimontato il chip e ho fatto una foto allo xell completo....come faccio a inserirla nel post???

**coffettierik** · 06-09-14

[url]https://www.dropbox.com/s/v1f9khxn39u981e/20140906_104157.jpg?dl=0[/url]

lo posto con dropbox ....

**zeruel85** · 06-09-14

Scusa ma hai RGH1 tu, non 2. Perchè dici che hai RGH2?

**Pa0l0ne** · 06-09-14

Originariamente Scritto da zeruel85

Scusa ma hai RGH1 tu, non 2. Perchè dici che hai RGH2?

Aggiungo che il fuseset02 non mente..

**zeruel85** · 06-09-14

Appunto.

La domanda successiva a questo punto è: perchè fare RJtag quando con RGH1 viaggi a cannone? Insta-glitch praticamente ad ogni boot.

**GAMEPLAYCONSOLE** · 06-09-14

Ma se hai RGH1 (che sulle falcon e jasper è stabile) perchè vuoi passare a R-JTAG ?

Scusa zeruel non avevo visto il tuo post

**Pa0l0ne** · 06-09-14

Citando "il sommo":

[url]http://www.consoleopen.com/forum/sezione-xbox-360-jtag-e-reset-glitch-hack/1128-fuseset-piccola-spiegazione-tecnica.html[/url]

Ma anche questo non era male:

Codice:

MADE BY xXXBOXxHACKERXx Kinect Dashboard Leaker
DO NOT COPY AS YOUR OWN WORK!
some infor from http://free60.org/Fusesets
SCROLL DOWN FOR INFO!

DEVKIT FUSES:

FUSESET 00:C0FFFFFFFFFFFFFF
FUSESET 01:0F0F0F0F0F0FF00F
FUSESET 02:0000000000000000
FUSESET 03:XXXXXXXXXXXXXXXX
FUSESET 04:XXXXXXXXXXXXXXXX
FUSESET 05:YYYYYYYYYYYYYYYY
FUSESET 06:YYYYYYYYYYYYYYYY
FUSESET 07:0000000000000000
FUSESET 08:0000000000000000
FUSESET 09:0000000000000000
FUSESET 10:0000000000000000
FUSESET 11:0000000000000000

RETAIL FUSES:

FUSESET 00:C0FFFFFFFFFFFFFF
FUSESET 01:0F0F0F0F0F0F0FF0
FUSESET 02:0F00000000000000
FUSESET 03:XXXXXXXXXXXXXXXX
FUSESET 04:XXXXXXXXXXXXXXXX
FUSESET 05:YYYYYYYYYYYYYYYY
FUSESET 06:YYYYYYYYYYYYYYYY
FUSESET 07:0000000000000000
FUSESET 08:0000000000000000
FUSESET 09:0000000000000000
FUSESET 10:0000000000000000
FUSESET 11:0000000000000000

RETAIL BINARY FUSES:

Fuseset 00: 1100011111111111111
Fuseset 01: 0101010101010110
Fuseset 02: 0100000000000000
Fuseset 03: 1001111110110000000101110100000000010101011101000101000000000000
Fuseset 04: 1001111110110000000101110100000000010101011101000101000000000000
Fuseset 05: 1101010101101001101110101101011010010101100011011011000000000000
Fuseset 06: 1101010101101001101110101101011010010101100011011011000000000000
Fuseset 07: 1111000000000000
Fuseset 08: 0000000000000000
Fuseset 09: 0000000000000000
Fuseset 10: 0000000000000000
Fuseset 11: 0000000000000000

ACTUAL RETAIL DUMP FOR BINARY:

fuseset 00: C0FFFFFFFFFFFFFF
fuseset 01: 0F0F0F0F0F0F0FF0
fuseset 02: 0F00000000000000
fuseset 03: 9FB0174015744DAF
fuseset 04: 9FB0174015744DAF
fuseset 05: D569BAD6958DAE9D
fuseset 06: D569BAD6958DAE9D
fuseset 07: FFFF000000000000
fuseset 08: 0000000000000000
fuseset 09: 0000000000000000
fuseset 10: 0000000000000000
fuseset 11: 0000000000000000

INFO:

FUSES 10-11 = 0A-0B
x+Y= CPU KEY


The dev kit fuseSet 2 is different. In another document by microsoft to make retail a dev  it says:

6) Reset the console type from Retail to Dev (Agile doc H03710)
RETAIL		00000002
DEVELOPMENT	00000001

DEV:
 Fuseset 01:0F0F0F0F0F0FF00F
RETAIL:
 Fuseset 01:0F0F0F0F0F0F0FF0

DEV BINARY:
 Fuseset 01: 0101010101011001
 RETIAL BINARY:
 Fuseset 01: 0101010101010110

so this means that it reverses 4 fuses in the procceses and retail is 2 so if retail is 0110
and dev is 1001 this mean you convert 2 together to 1-2 apart to get f00f


The size of the Retail version is: 16.5 MB (17,301,504 bytes)
The size of veron Devkit fact: 66.0 MB (69,206,016 bytes)


The Xbox 360's Xenon CPU has 768 bits of eFUSE, a technology invented by IBM, and implemented
in some of it's processors. eFUSEs are hardware fuses on the CPU, and can be "blown" to a binary
 value (1 being blown, and 0 being un-blown) in the Xbox 360, there are 768 fuses, that make up
the fusesets. Though each fuseset can be blown individually, they are blown in groups of 8 to
make a hexadecimal value for the CPU key, and fuseline 00, instead of a binary value, which is
what XeLL will actually display. Technically, there are only 192 viewable fuses.


Fusesets 00 and 01
These are burned at the factory, after the console is manufactured, they show whether
 the console is a devkit or not. They also disable CPU JTAG after the console's flash is programed.

Fuseset 02
This is the lockdown counter for the 2BL/CB (The 2nd Bootloader, stored in NAND Flash)
 One of these are burned everytime the console updates it's bootloader (Which isn't very often)
 this is the reason that there is no way to recover a JTAG that has been updated to 2.0.8***.0,
 even is you have the CPU key, (2BL is encrypted with the CPU/1BL key, but is signed with
 Microsoft's private key so you can't change the lockdown counter in the NAND. The bootloader
 will fail signature checks, and panic)

Fusesets 03-06
These make up the CPU key. These start out as all zero's, and are burned presumably at random when
 the console boots for the first time, they are used to encrypt the keyvault, and the bootloader
sections. The CPU key is unique to each console, and is sometimes refered to as the "per-box key"
To find the CPU key, add fusesets 03, and 05, OR 04 and 06. For example, this console's CPU key
would be "XXXXXXXXXXXXXXXXYYYYYYYYYYYYYYYY."

Fusesets 07-11
These make up the console's "Lockdown Counter." They are blown after each dashboard update starting
 with the update from 4532/4548 to 4598. They prevent a previous version of the dashboard from being
 run on an updated console. There are enough eFUSEs in this section for Microsoft to update the
console roughly 80 times. The lockdown counter of this console is at FFFF00000..., this means that
it has recieved 4 dashboard updates since 2.0.4548.0 ran on it. Microsoft originally intended to
only blow an eFUSE when a system update patched a critical vulnerability (Like the HV vulnerability
in 4532 and 4548) but has now decided to blow an eFUSE with every update since the update to 4598.
In the NAND's 6BL(CF) section, there is another lockdown counter that should match the one of the
eFUSEs. If it doesn't match, the console will panic on boot, and will show a RRoD. Now, here's the
good part! If we know the CPU key of the console, we can decrypt the 6BL, and change the lockdown
counter in the NAND to match the one on the console, and therefore run an older dashboard. Since
the 6BL isn't signed with Microsoft's private key, we can edit it as we please, so long as we have
 our CPU key.
